StockCode
300713
215kW/215kWh Mobile ESS Charger
MobileEVC 215-215-30
The Mobile EVC Family is a smart, mobile battery power station designed as a clean, quiet and efficient alternative or supplement to diesel generators. It integrates battery, PCS, HVAC, fire safety system and hybrid energy controller into an all-in-one mobile solution.
The system supports multiple operating modes, including off-grid, mobile island, grid-connected and hybrid diesel-generator operation. With AI-based EMS, PowerBoost technology and flexible scalability, it can supply stable power for construction sites, events, industrial operations, remote areas and emergency applications.
With optional built-in EV charging modules, Mobile EVC can also work as a portable EV charging station, supporting CCS2 fast charging for roadside assistance, remote charging and temporary charging demand.
The system supports multiple operating modes, including off-grid, mobile island, grid-connected and hybrid diesel-generator operation. With AI-based EMS, PowerBoost technology and flexible scalability, it can supply stable power for construction sites, events, industrial operations, remote areas and emergency applications.
With optional built-in EV charging modules, Mobile EVC can also work as a portable EV charging station, supporting CCS2 fast charging for roadside assistance, remote charging and temporary charging demand.
Product Features
Product Parameters
MobileEVC 215-215-30
General
AC Power
Battery
EV Charging System
Optional Features
General
| Item | Specifications | |
|---|---|---|
| General | Model | MobileEVC 215-215-30 |
| Configuration | 215 kVA / 215 kWh | |
| Dimensions | 2750×2150×2198 mm | |
| Weight | 5.9 ton | |
| Container Type | Outdoor Cabinet | |
| Operating Ambient Temperature | -20~55 °C | |
| Humidity | 0% to 95% (No Condensation) | |
| Full Performance Operating Altitude | ≤2000 m | |
| Acoustic Level at 1.5 m | <75 dB | |
| Ingress Protection / Anticorrosion | IP55 / C4 | |
| Output Isolation | Isolation Transformer | |
| Iot | Ethernet, RS485 | |
| Connection with Dg | Ac Coupling | |
| Expected Lifetime | >10 Years |
AC Power
| Item | Specifications | |
|---|---|---|
| AC Power | Output Rated Power Capacity | 200 kW (With Max Charging Power 30 kW) |
| Output Overload Power/Powerboost (@60 Sec Per 600 Sec) | 250 kVA, 83 kVA Per Phase | |
| Output Overload Power/Powerboost (@10 Sec Per 600 Sec) | 300 kVA, 100 kVA Per Phase | |
| Input Max Power | 210 kW | |
| Input/Output Rated Voltage | 380/400/415 Vac @ 3 Phases 3L/N/Pe | |
| Input Voltage Range | 360~433 Vac, Software Adjustable | |
| Input/Output Frequency | 50 Hz / 60 Hz ±2.5 Hz, Software Adjustable | |
| Input/Output Connection | Copper Busbar Or Powerlock | |
| Circuit Breaker | Elcb (Mccb Optional) | |
| Upstream Leakage Current | <30 mA | |
| Pcs THDi (Total Harmonic Distortion-Current) | ≤3% |
Battery
| Item | Specifications | |
|---|---|---|
| Battery | Battery Cell Type | CATL LFP 285 Ah |
| Rated Energy Storage Capacity | 218 kWh | |
| Operating Dc Voltage | 672–876 Vdc | |
| Depth of Discharge (DoD) | 90% / 80% | |
| Max Charging Rate | 1C | |
| Rated Discharge Rate | 1C | |
| Expected Lifecycles | 5000 Cycles | |
| Battery Management System | Designed by EjT | |
| Fastest Charging Duration | 80 min |
EV Charging System
| Item | Specifications | |
|---|---|---|
| EV Charging System | EV Charging Power | 30 kW |
| DC Output Voltage Range | 200–1000 Vdc, With an Error of ±1 Vdc | |
| Charging Interface | CCS2 | |
| Maximum Output Power | 30 kW | |
| Touch Screen | 10.1-Inch | |
| Protection Functions | Overvoltage Protection, Overcurrent Protection, Short Circuit Protection, Battery Reverse Connection Protection, Insulation Protection, Over-Temperature Protection | |
| Certification | IEC/EN 61851-1, IEC/EN 61851-23, IEC/EN 61851-24, IEC/EN 62196-3 |
Optional Features
| Item | Specifications | |
|---|---|---|
| Optional Features | Range-Extended Charging by Ac Power | 80 kW Standard / 80 kW Max / 380/400/415 Vac, 50/60 Hz / Upstream Leakage Current <30 mA |
| Smartgenset (Built-In Smart Diesel Generator Management System) | Yes | |
| Premium Input/Output Connection | Powerlock (Max 400 A), Cee Form Connector (16 A / 63 A) | |
| Iot | 4G | |
| Ai Watt by Cloud with App | Yes | |
| Web Remote Control | Yes | |
| GPS | Yes | |
| Built-In / Add-On Fast Ev Charger | 30 kW CCS2 | |
| Grid Connection | ENIEC 50549-1, VDE 4105/4110, G99/G100, AS/NZS 4777 |
