StockCode
300713
HVDC Power Supply Monitor
TPMH-SA60
The TPMH-SA60 monitoring module serves as the data processing center for the High-Voltage Direct Current (HVDC) power system. It collects operational data through two CAN interfaces (connecting to rectifier modules and feeder monitoring modules) and two RS485 communication ports (connecting to AC/DC detection units, battery monitors, etc.). Based on this data, the module automatically manages the equalizing and floating charge conversion for the battery bank.
Product Features
Communication & Time SynchronizationIntegrates 3 RS485 communication ports and supports B-code time synchronization.
Features 2 CAN communication ports for internal communication.
01
HMI & General InterfacesSupports WEB access for parameter configuration.
Equipped with 2 USB ports for firmware upgrade and file export.
Features a 7-inch color touchscreen.
Operating power supply: DC 12~24V.
02
Product Parameters
Application Scenarios
Data Center
Network Center
Telecom Operator
Data Center
